Water Bath Thawing Machine
Uses heated water for uniform surface thawing before coating. Electric or steam heating, automatic temperature control, and VFD belt speed support process flexibility.
Model: CMK-RSJD600 / CMK-RSJD800 / CMK-RSJD1000
Features of Water Bath Thawing Machine
- ✓Electric or steam water heating delivers uniform surface thawing.
- ✓Belt speed is VFD-controlled from 2~15m/min.
- ✓Width options: 600mm, 800mm, and 1000mm.
- ✓Automatic temperature regulation maintains the set process temperature.
- ✓Even thawing helps increase product yield.
- ✓Full stainless steel construction supports long-term continuous use.
About This Machine
The Water Bath Thawing Machine uses electric or steam heating to warm water, which then provides uniform surface thawing of frozen products. Even thawing helps increase product yield. Temperature is settable per customer process requirements with fully automatic regulation. Belt speed is VFD-adjustable.
Thawing Process
Electric or steam water heating delivers uniform surface thawing, helping to increase product yield. Temperature is settable per customer process requirements with fully automatic regulation. VFD-controlled belt speed allows flexible adjustment to suit different product thawing time requirements.
Equipment Features
Temperature precisely settable per customer process requirements with fully automatic regulation. Belt speed 2~15m/min (VFD-controlled) for flexible thawing time adjustment. Three width options: 600mm, 800mm, 1000mm. Full stainless steel construction for reliable long-term continuous use. Integrates with downstream battering & breading production lines.
Applications
Suitable for surface thawing of frozen products prior to pre-dusting, battering, or breading.
Technical Parameters
- CMK-RSJD600
- 2570 × 1050 × 1460mm
- Effective Width
- 600mm
- Belt Speed
- 2 ~ 15m/min (adjustable)
- Conveyor Height
- 900mm
- Thawing Temp
- 40 ~ 50°C
- Total Power
- 12.75kw
- Heating Power
- 12kw
- Capacity
- 12,000 ~ 20,000 pcs/h
- CMK-RSJD800
- 2570 × 1250 × 1460mm
- Effective Width
- 800mm
- Belt Speed
- 2 ~ 15m/min (adjustable)
- Conveyor Height
- 900mm
- Thawing Temp
- 40 ~ 50°C
- Total Power
- 19.1kw
- Heating Power
- 18kw
- Capacity
- 15,000 ~ 25,000 pcs/h
- CMK-RSJD1000
- 2570 × 1450 × 1460mm
- Effective Width
- 1000mm
- Belt Speed
- 2 ~ 15m/min (adjustable)
- Conveyor Height
- 900mm
- Thawing Temp
- 40 ~ 50°C
- Total Power
- 25.5kw
- Heating Power
- 24kw
- Capacity
- 18,000 ~ 32,000 pcs/h
